Description
Alfons Haar Sliding Vane Pump
Overview
Alfons Haar self priming sliding vane pumps, from GO Industrial, are significantly smaller than most competitors at equivalent flow rates, almost half the size, half the weight and faster than other pumps currently on the market.
With a choice of bare shaft (for electric or diesel driven motors), hydraulically driven or direct mount versions, Alfons Haar have possibly the widest range of vane pumps available for fuel transfer, in the market today.
Stocked Pump Kits
| Assembly | Part # |
DP Max (bar) |
RPM |
Flow Rate (LPM) |
| FPCC50-153 3kW 8 pole motor | A2BCA3.0X4158 | 3.5 | 715 | 109 |
| FPCC50-153 1.1kW 6 pole motor | A2BAA1.1X4156 | 3.5 | 940 | 143 |
| FPCC50-213 4.0kW 4 pole motor | C2BBA4.0X4154 | 4.5 | 1463 | 311 |
| FPCC50-213 4.0kW 6 pole motor | C2BCA4.0X4156 | 4.5 | 975 | 208 |
| FPO65-407 4.0kW 6 pole motor | D2HDA4.0X4156 | 3.5 | 975 | 397 |
| FPO65-407 5.5kW 6 pole motor | D2KDA5.5X4156 | 6.5 | 975 | 397 |
| FPO65-600 5.5kW 6 pole motor | D2HDA5.5X4156 | 3.5 | 975 | 585 |
| FPO65-600 7.5kW 6 pole motor | D2KFA7.5X4156 | 6.5 | 975 | 585 |
| FPO65-600 7.5kW 4 pole motor | D2HDA7.5X4154 | 3.5 | 1463 | 877 |
| FPO65-600 11kW 4 pole motor | D2KFA11X4154 | 6.5 | 1463 | 877 |
| FPO80-900 7.5kW 6 pole motor | E2HGA7.5X4156 | 3.5 | 975 | 878 |
| FPO80-900 11kW 6 pole motor | E2KGA11X4156 | 6.5 | 975 | 878 |
| FPO100-975 7.5kW 6 pole motor | F2HHA7.5X4156 | 3.5 | 975 | 951 |
| FPO100-975 11kW 6 pole motor | F2GHA11X4156 | 6 | 975 | 951 |
| FPO100-1308 7.5kW 8 pole motor | F2HHA7.5X4158 | 3.5 | 731 | 956 |
| FPO100-1308 15kW 8 pole motor | F2GLA15X4158 | 6 | 731 | 956 |
| FPO100-1308 15kW 6 pole motor | F2HKA15X4156 | 3.5 | 975 | 1275 |
| FPO100-1308 18.5kW 6 pole motor | F2GLA18.5X4156 | 6 | 975 | 1275 |
| FPO100-1308 11kW 6 pole motor | F2HHA11X4156 | 3.5 | 975 | 1275 |
