Go Ball Valve – Double-Acting Pneumatic Actuator, ANSI 150 Flanged, 316 Stainless Steel, 3-Way, 1/2″–4″ (BLS3FADA)

Price range: $76.23 through $99.83

Quantity
SKU: N/A Category: Brand:

Description

GO Ball Valves Actuated Double Acting Pneumatic Flanged ANSI 150# 3 Way BLS3FADA

Overview

High performance 3 way full bore 316 Stainless Steel ball valve with ANSI 150 flanged connections and a double acting pneumatic actuator. Self adjusting stem packing assembly with belleville spring for temperature fluctuations and vibration. Pre drilled metric ISO5211 direct mounting pad to minimise any thermal transfer from valve to actuator. Reinforced PTFE seats for temperatures up to 180°C. Anodized aluminium rack and pinion actuator with visual indicator, namur interface and stop adjustments.

Explore more from our collection.

Additional information

Size

1/2" (15mm), 3/4" (20mm), 1" (25mm), 1 1/4" (32mm), 1 1/2" (40mm), 2" (50mm), 2 1/2" (65mm), 3" (80mm), 4" (100mm)
Body Material

SS316, Cast Steel
