Go Ball Valves Actuated Spring Return Pneumatic High Pressure Two Piece Full Bore 316 Stainless Scr Bsp Blshpsr 1
Go Ball Valves Actuated Spring Return Pneumatic High Pressure Two Piece Full Bore 316 Stainless Scr Bsp Blshpsr 2
Go Ball Valves Actuated Spring Return Pneumatic High Pressure Two Piece Full Bore 316 Stainless Scr Bsp Blshpsr 3

High-Pressure Spring-Return Pneumatic Ball Valve – Two-Piece Full-Bore Design in 316 Stainless Steel, 1/4″ to 2″ BSP/SCR Threaded

Price range: $84.48 through $98.01

Quantity
SKU: N/A Category: Brand:

Description

GO Ball Valves Actuated Spring Return Pneumatic High Pressure Two Piece Full Bore 316 Stainless Scr BSP BLSHPSR

Overview

Series BLSHP high performance 316 stainless steel ball valves are specifically designed for high pressure applications. Delrin seats enable pressures up to 204 BAR or 3000 psi at 38°C. Comes with spring return (fail open or fail closed) anodised aluminium pneumatic actuator with visual indicator.

Explore more from our collection.

Additional information

Size

1/4" (8mm), 3/8" (10mm), 1/2" (15mm), 3/4" (20mm), 1" (25mm), 1 1/2" (40mm), 2" (50mm)
