Wireless Transponder for WTS Systems

Description

WALDO TIMING SYSTEM
A MonacoRC Exclusive
WTS Transponder designed a special Edition called Diamond Edition exclusively for MonacoRC.
The WTS Diamond Edition thanks to its transparent case is the ideal choice for those who love to have a refined look on their car.
Specification:

Dimesions: 19x19x6mm
Weight: 4gr
Temperature Range: 0-50 degree (Celsius)
Humidity: max 90% relative
Signal Transfer: Magnetic Induction
Transponder Position: Horizontal Max Height 15cm
Power Feed: RX Channel or Battery
Connection Plug: Standard Servo Plug
Operating Voltage: 3V-16V DC (Reverse Polarity Protected)
Power Consumption: 14mAh @ 6V
Display LED: Ultra-Bright RED

Instruction:

The WTS Transponder is compatible with all RC System including RC Version 4 Decoders with Firmware 4.4 or lower.

Operation is purely lap counting and timing using its 7 DIGIT ID number.
The Transponder is ready to be used right away simply by connecting to a Battery or plugging into a free Reciver Channel or BATT Socket.
WTS Power Cable can be easily replaced. Preheat black part of Transponder to 80 degree (Celsius) and slowly remove PCB from Case. Solder new Cable to PCB pads. Be sure to respect the polarity. Insert PCB agian into the Case. Use Hot Glue to close the Case.
