Go Lugged Butterfly Valve with Cast Iron Body, 316 Stainless Steel Disc, EPDM Liner, and Double-Acting Pneumatic Actuator (2″–24″)

Price range: $70.95 through $99.99

Quantity
SKU: N/A Category: Brand:

Description

GO CI Body 316 SS Disc EPDM Liner BFLDA Butterfly Valves Actuated Double Acting Pneumatic Lugged

Overview

The BFL series of lugged butterfly valves (table E standard) have a cast iron body, 316 S.S disc and an EPDM seat making them suited to a wide range of general water and industrial applications. They are operated by either a high quality anodised aluminium double acting (rack and pinion design) pneumatic actuator. The unique bonded catridge design of the valve gives it a longer life span, allows vacuum to be run through it and makes it replaceable if ever the need should arise.

      Explore more from our collection.

      Additional information

      Size

      2" (50mm), 2 1/2" (65mm), 3" (80mm), 4" (100mm), 5" (125mm), 6" (150mm), 8" (200mm), 10" (250mm), 12" (300mm)
      Seat

      EPDM/NBR, Viton
      Flange

      Table E, ANSI 150
