Pneumatic Spring-Return Actuated Lugged Butterfly Valve with Cast Iron Body, 316 Stainless Steel Disc, and EPDM Liner (2″–24″)

Price range: $70.18 through $98.12

Quantity
SKU: N/A Category: Brand:

Description

GO CI Body 316 SS Disc EPDM Liner BFLSR Butterfly Valves Actuated Spring Return Pneumatic Lugged

Overview

The BFL series of lugged butterfly valves (table E standard) have a cast iron body, 316 S.S disc and an EPDM seat making them suited to a wide range of general water and industrial applications. They are operated by either a high quality anodised aluminium spring return(rack and pinion design) pneumatic actuator. This allows the valve to return to a fail safe position should air be lost. The unique bonded cartridge design of the valve gives it a longer life span, allows vacuum to be run through it and makes it replaceable if ever the need should arise.

        Explore more from our collection.

        Additional information

        Size

        2" (50mm), 2 1/2" (65mm), 3" (80mm), 4" (100mm), 5" (125mm), 6" (150mm), 8" (200mm), 10" (250mm), 12" (300mm)
        Seat

        EPDM/NBR, Viton
        Flange

        Table E, ANSI 150
