Manual Butterfly Valve with Cast Iron Body, 316 Stainless Steel Disc, and EPDM Liner – 2″ to 24″

Price range: $0.00 through $95.29

Quantity
SKU: N/A Category: Brand:

Description

GO CI Body 316 SS Disc EPDM Liner BFD Manual Butterfly Valves

Overview

The BFD series has a fusion bonded epoxy coated cast iron body, 316 S.S disc and an EPDM seat making them suited to a wide range of general water applications. These wafer butterfly valves will fit all standard flanges and are operated by either a lever or gear box. The unique bonded cartridge design gives them a longer life span, allows vacuum to be run through them and makes them replaceable if ever the need should arise. Designed & manufactured in accordance with API609, inspected and tested in accordance with API598.

Explore more from our collection.

Additional information

Size

2" (50mm), 2 1/2" (65mm), 3" (80mm), 4" (100mm), 5" (125mm), 6" (150mm), 8" (200mm), 10" (250mm), 12" (300mm), 14" (350mm), 16" (400mm), 18" (450mm), 20" (500mm), 24" (600mm)
Seat

EPDM/NBR, Viton
