Pneumatic Double-Acting Butterfly Valve with Cast Iron Body, 316 Stainless Steel Disc, and EPDM Lined Seat (2″–24″)

Price range: $71.50 through $97.60

Quantity
SKU: N/A Category: Brand:

Description

GO CI Body 316 SS Disc EPDM Liner BFDDA Butterfly Valves Actuated Double Acting Pneumatic

Overview

The BFD series has a cast iron body, 316 S.S disc, EPDM seat and a double acting pneumatic actuator making it suited to a wide range of industrial applications. These wafer butterfly valves will fit all standard flanges and are operated by a high quality double acting (rack and pionion design) anodised aluminium pneumatic actuator.

Explore more from our collection.

Additional information

Size

2" (50mm), 2 1/2" (65mm), 3" (80mm), 4" (100mm), 5" (125mm), 6" (150mm), 8" (200mm), 10" (250mm), 12" (300mm), 14" (350mm), 16" (400mm), 18" (450mm), 20" (500mm), 24" (600mm)
Seat

EPDM/NBR, Viton
