V-Port Pneumatic Ball Valve – Double-Acting, 316 Stainless Steel, 3-Piece Full-Bore, 1/2″ to 4″ (BLVDA Series)

Price range: $74.58 through $94.88

Quantity
SKU: N/A Category: Brand:

Description

GO Ball Valves V Port Actuated Double Acting Pneumatic 316 Stainless 3 Piece Full Bore BLVDA

Overview

High performance 3 piece full bore 316 Stainless Steel V Port Ball Valve with BSP threaded connections and a double acting pneumatic actuator. Self adjusting stem packing assembly with Belleville spring for temperature fluctuations and vibration. Pre drilled metric hole on ISO5211 direct mounting pad to minimise any thermal transfer from valve to actuator. Reinforced PTFE seats for temperatures up to 180°C. Anodised aluminium spring return pneumatic actuator which allows a fail safe position if air is lost.

    Explore more from our collection.

    Additional information

    Size

    1/2" (15mm), 3/4" (20mm), 1" (25mm), 1 1/2" (40mm), 2" (50mm), 3" (80mm), 4" (100mm)
